Product & Service

Description

It is used for clinical dilatation and channel establishment in patients with renal stones or hydronephrosis during percutaneous renal puncture expansion and drainage as well as endoscopic surgical instrument placement.

Features

01

The peeling sheath is made of Teflon and its inner surface is very smooth, which reduces the damage to the mucous membrane of the patient. In addition, the friction coefficient of tube surface is extremely low,the ductility of tube body is excellent, and it is easy to tear the sheath apart;
02

The dilatation tube and the tip of the guide needle can be visualized under X-ray, and the tip is smooth
03

The sheath is gradually expanded to establish the access channel;
04

The two ends of the guidewire are J-shaped and straight, respectively, and the tip is soft. The middle portion of the guidewire is rigid with good support. It is extremely difficult for the guidewire to prolapse、 in the renal pelvis and damage the tissue;
05

The tube body is marked with scale for accurate positioning during puncture.

Specification

Serial No.	Order No.	Model	Dilator	Sheath	Optional accessories
Serial No.	Order No.	Model	Dilator	Sheath	Puncture needle	Guidewire
1	330108	08*180A	8F	8F	\	\
2	330110	10*180A	10F	10F	\	\
3	330112	12*180A	12F	12F	\	\
4	330114	14*180A	14F	14F	\	\
5	330116	16*180A	16F	16F	\	\
6	330118	18*180A	18F	18F	\	\
7	330120	20*180A	20F	20F	\	\
8	330122	22*180A	22F	22F	\	\
9	330208	08*180B	8F	8F	18G、22G	0.035〞
					18G、22G	\
					18G	\
					22G	\
					18G	0.035〞
					22G	0.035〞
10	330210	10*180B	10F	10F	18G、22G	0.035〞
					18G、22G	\
					18G	\
					22G	\
					18G	0.035〞
					22G	0.035〞
11	330212	12*180B	8F、10F、12F	12F	18G、22G	0.035〞
					18G、22G	\
					18G	\
					22G	\
					18G	0.035〞
					22G	0.035〞
12	330214	14*180B	8F、10F、12F、14F	14F	18G、22G	0.035〞
					18G、22G	\
					18G	\
					22G	\
					18G	0.035〞
					22G	0.035〞
13	330216	16*180B	8F、10F、12F、14F、16F	16F	18G、22G	0.035〞
					18G、22G	\
					18G	\
					22G	\
					18G	0.035〞
					22G	0.035〞
14	330218	18*180B	8F、10F、12F、14F、16F、18F	18F	18G、22G	0.035〞
					18G、22G	\
					18G	\
					22G	\
					18G	0.035〞
					22G	0.035〞
15	330220	20*180B	8F、10F、12F、14F、16F、18F、20F	20F	18G、22G	0.035〞
					18G、22G	\
					18G	\
					22G	\
					18G	0.035〞
					22G	0.035〞
16	330222	22*180B	8F、10F、12F、14F、16F、18F、20F、22F	22F	18G、22G	0.035〞
					18G、22G	\
					18G	\
					22G	\
					18G	0.035〞
					22G	0.035〞
